Have you ever thought about how you send and receive email?. Did you ever wonder how this works behind the scenes?. In this article, we're going to write both an SMTP server and client based on RFC5321. We're not going to implement the whole RFC, at least we can sending and receive an email.

What you need to know before continue

Before writing the server and client, I'm going to write the whole project using Rust. If you don't have any experience using Rust, you can still read these articles an implement it in another language. I'm going to explain step-by-step, then write the code to make sure you can implement it in another language.

SMTP Protocol

Before writing the code, we need to know the process of sending and receiving messages. Here is an example of communication between the client and server using the SMTP protocol:

S: 220 smtp.example.com ESMTP Postfix
C: HELO relay.example.org
S: 250 Hello relay.example.org, I am glad to meet you
C: MAIL FROM:<[email protected]>
S: 250 Ok
C: RCPT TO:<[email protected]>
S: 250 Ok
C: RCPT TO:<[email protected]>
S: 250 Ok
C: DATA
S: 354 End data with <CR><LF>.<CR><LF>
C: From: "Bob Example" <[email protected]>
C: To: "Alice Example" <[email protected]>
C: Cc: [email protected]
C: Date: Tue, 15 Jan 2008 16:02:43 -0500
C: Subject: Test message
C:
C: Hello Alice.
C: This is a test message with 5 header fields and 4 lines in the message body.
C: Your friend,
C: Bob
C: .
S: 250 Ok: queued as 12345
C: QUIT
S: 221 Bye
{The server closes the connection}

As you can see, the protocol is really simple like the name. there some command defines a particular function on the SMTP session and i’m gonna explain step-by-step later.

SMTP Command

Here is the list SMTP Command we gonna use in this articles.

Command Name	Explanation
HELO/EHLO	A command that indicate the SMTP Session is start
MAIL	Used to initiate a mail transaction
RCPT	Used to identify an individual recipient of the mail data
DATA	Used to initiate the transfer of actual/body mail data
RSET	Used to indicate that current mail transaction will be aborted
NOOP	It similar to “ping”. it used to keep the connection alive or test if the client is still connected to server
QUIT	Used to close the connection

Start Writing the Code

First of all, we're going to create a new project using Rust. I'm going to use tokio to handle concurrent connections. We'll be running our SMTP Server over TCP (if you carefully read the RFC, SMTP can run on other transports, but we use TCP because the RFC recommends running over TCP). Before write the main function, you need a tokio into cargo.toml.

toml

[package]
name = "smtp-server"
version = "0.1.0"
edition = "2021"

[dependencies]
tokio = { version = "1", features = ["full"] }

Next, here is our starter main function. By default, an SMTP server uses PORT 25, but because I ran it locally and didn't want it to run as root, I set the port to 2525.

rust

use std::error::Error;

use tokio::{
    io::{AsyncBufReadExt, BufReader},
    net::{TcpListener, TcpStream},
};

#[tokio::main]
async fn main() {
    let server = TcpListener::bind("127.0.0.1:2525")
        .await
        .expect("Failed to start server, maybe the port already used");

    println!("Server is running...");

    loop {
        match server.accept().await {
            Ok((stream, addr)) => {
                println!("New connection from {}", addr);

                tokio::spawn(async move {
                    if let Err(e) = handle_connection(stream).await {
                        eprintln!("Error handling connection from {}: {}", addr, e);
                    }
                });
            }
            Err(e) => {
                println!("Error accepting connection: {}", e);
            }
        }
    }
}

async fn handle_connection(stream: TcpStream) -> Result<(), Box<dyn Error>> {
    let mut reader = BufReader::new(stream);

    let mut line = String::new();

    loop {
        line.clear(); // clear the line for each iteration

        let bytes_read = reader.read_line(&mut line).await?;

        if bytes_read == 0 {
            break;
        }

        println!("Received: {}", line);
    }

    Ok(())
}

Now, we are going to test our server. I'm going to use Golang for the test because it's really simple. Here is the test code.

package main

import (
    "fmt"
    "net/smtp"
)

const CRLF = "\r\n"

func main() {
    serverAddress := "localhost:2525"

    from := "[email protected]"
    to := []string{"[email protected]", "[email protected]"}
    subject := "subject gonna be here"

    body := `
    <h1>Hello World</h1>
    <p>This is a paragraph.</p>

    <p>This is another paragraph.</p>
    <p>This is the last paragraph.</p>

    <p>And this is the last paragraph.</p>
    <p>And this is the last paragraph.</p>
    `

    message := []byte(
        "From: " + from + CRLF +
            "To: " + to[0] + CRLF +
            "Subject: " + subject + CRLF + CRLF +
            body + CRLF,
    )

    // auth := smtp.PlainAuth("",
    //  "test",
    //  "test",
    //  "localhost",
    // )

    err := smtp.SendMail(
        serverAddress,
        // auth,
        nil,
        from,
        to,
        message,
    )
    if err != nil {
        fmt.Println("Error sending email:", err)
        return
    }

    fmt.Println("Email sent successfully!")
}

Sending the initial message

When you try to run the server and then the client, you'll see nothing on both sides because the client is waiting for the initial message but the server doesn't send anything. Now, we're going to send the greeting on our server.

Change our handle_connection function into like this.

rust

async fn handle_connection(mut stream: TcpStream) -> Result<(), Box<dyn Error>> {
    let (reader, mut writer) = stream.split();

    // send the greeting message
    writer
        .write_all(reply(220, "Service ready").as_bytes())
        .await
        .unwrap();

    let mut buffer = BufReader::new(reader);
    let mut line = String::new();

    loop {
        line.clear(); // clear the line for each iteration

        let bytes_read = reader.read_line(&mut line).await?;

        if bytes_read == 0 {
            println!("Connection closed by client");
            break;
        }

        println!("Received: {}", line);
    }

    Ok(())
}

fn reply(code: i32, message: &str) -> String {
    println!("Server: {}", message);

    format!("{} {}\r\n", code, message)
}

we sending message “220 Service Ready” it means the server is ready to start SMTP Session. When you running both the server and the client, here is the output on the server.

bash

[08:19:04] raden :: seior  ➜  Rust/project/smtp-server ‹master*› » cargo run
   Compiling smtp-server v0.1.0 (/Users/raden/Development/Rust/project/smtp-server)
    Finished `dev` profile [unoptimized + debuginfo] target(s) in 0.60s
     Running `target/debug/smtp-server`
Server is running...
New connection from 127.0.0.1:61876
Server: Service ready
Received: EHLO localhost

Parsing the command

When you look at the client and server, you'll notice they're now stuck after sending the greeting command because the server expects the HELO command from the client. Now, we're going to parse the command from the client. First, let's create a struct named Command and the function we'll use for parsing the command.

rust

struct Command {
    command: String,
    args: Vec<String>,
}

impl Command {
    fn parse(&mut self, line: &str) {
        let parts: Vec<&str> = line.split(" ").collect();

        // check if parts is empty
        if parts.is_empty() {
            return;
        }

        self.command = parts[0].to_uppercase();

        self.args = parts[1..].iter().map(|s| s.to_string()).collect();
    }
}

After that, edit our handle_connection function into like this.

rust

async fn handle_connection(mut stream: TcpStream) -> Result<(), Box<dyn Error>> {
    let (reader, mut writer) = stream.split();

    // send the greeting message
    writer
        .write_all(reply(220, "Service ready").as_bytes())
        .await
        .unwrap();

    let mut buffer = BufReader::new(reader);
    let mut line = String::new();
    let mut cmd = Command::new();

    loop {
        line.clear(); // clear the line for each iteration

        let bytes_read = reader.read_line(&mut line).await?;

        if bytes_read == 0 {
            println!("Connection closed by client");
            break;
        }

        println!("Received: {}", line.trim_end());

        cmd.parse(&line);
    }

    Ok(())
}

Instead of using strings for the command, it's better to write an enum for handling the command. Now, we'll create enums for the SmtpCommand and status codes.

rust

const SMTP_STATUS_READY: i32 = 220;
const SMTP_STATUS_BYE: i32 = 221;
const SMTP_STATUS_OK: i32 = 250;
const SMTP_STATUS_SEND_DATA: i32 = 354;
const SMTP_STATUS_AUTH_SUCCESS: i32 = 235;
const SMTP_STATUS_ERROR_COMMAND_UNRECOGNIZED: i32 = 500;
const SMTP_STATUS_ERROR_SYNTAX: i32 = 501;
const SMTP_STATUS_ERROR_BAD_SEQUENCE: i32 = 503;

#[derive(Debug, PartialEq, Eq)]
enum SmtpCommand {
    Helo,
    Ehlo,
    Auth,
    Mail,
    Rcpt,
    Data,
    Rset,
    Noop,
    Quit,
}

#[derive(Debug, PartialEq, Eq)]
struct ParseCommandError;

impl SmtpCommand {
    fn new() -> Option<Self> {
        None
    }
}

impl FromStr for SmtpCommand {
    type Err = ParseCommandError;

    fn from_str(s: &str) -> Result<Self, Self::Err> {
        match s.to_uppercase().as_str() {
            "HELO" => Ok(SmtpCommand::Helo),
            "EHLO" => Ok(SmtpCommand::Ehlo),
            "AUTH" => Ok(SmtpCommand::Auth),
            "MAIL" => Ok(SmtpCommand::Mail),
            "RCPT" => Ok(SmtpCommand::Rcpt),
            "DATA" => Ok(SmtpCommand::Data),
            "RSET" => Ok(SmtpCommand::Rset),
            "NOOP" => Ok(SmtpCommand::Noop),
            "QUIT" => Ok(SmtpCommand::Quit),
            _ => Err(ParseCommandError),
        }
    }
}

struct Command {
    command: Option<SmtpCommand>,
    args: Vec<String>,
}

impl Command {
    fn new() -> Self {
        Self {
            command: SmtpCommand::new(),
            args: Vec::new(),
        }
    }

    fn parse(&mut self, line: &str) {
        let trimmed_line = line.trim();
        if trimmed_line.is_empty() {
            self.command = None;
            self.args.clear();
            return;
        }

        let parts: Vec<&str> = trimmed_line.split_whitespace().collect();

        self.command = parts[0].parse().ok();
        self.args = parts[1..].iter().map(|s| s.to_string()).collect();
    }
}

Handle HELO/EHLO Command

For handling the HELO/EHLO command, simply send the status OK and you can set any message you want.

rust

async fn handle_connection(mut stream: TcpStream) -> Result<(), Box<dyn Error>> {
    ...

    loop {
        line.clear(); // clear the line for each iteration

        let bytes_read = buffer.read_line(&mut line).await?;

        if bytes_read == 0 {
            println!("Connection closed by client");
            break;
        }

        println!("Received: {}", line.trim_end());

        cmd.parse(&line);

        match cmd.command {
            Some(SmtpCommand::Helo) | Some(SmtpCommand::Ehlo) => {
                let response = reply(SMTP_STATUS_OK, "HELO from server");

                writer.write_all(response.as_bytes()).await?;
            }
            Some(SmtpCommand::Auth) => {}
            Some(SmtpCommand::Mail) => {}
            Some(SmtpCommand::Rcpt) => {}
            Some(SmtpCommand::Data) => {}
            Some(SmtpCommand::Rset) => {}
            Some(SmtpCommand::Noop) => {}
            Some(SmtpCommand::Quit) => {}
            None => {
                let response = reply(
                    SMTP_STATUS_ERROR_COMMAND_UNRECOGNIZED,
                    "Unrecognized command",
                );

                writer.write_all(response.as_bytes()).await?;
            }
        }
    }

    Ok(())
}

After that, you can run both the server and client.

rust

Server is running...
New connection from 127.0.0.1:63732
Server: Service ready
Received: EHLO localhost
Server: HELO from server

Handle MAIL Command

Next, we'll handle the MAIL command. For the MAIL command, the client needs to send one argument containing the email address. Before handling the command, we need to make a mail struct containing the args from the client.

rust

#[derive(Debug)]
struct Mail {
    from: String,
    to: Vec<String>,
    header: HashMap<String, String>,
    body: String,
}

impl Mail {
    fn new() -> Self {
        Self {
            from: String::new(),
            to: Vec::new(),
            header: HashMap::new(),
            body: String::new(),
        }
    }
}

After that, edit our handle_connection function.

rust

async fn handle_connection(mut stream: TcpStream) -> Result<(), Box<dyn Error>> {
    ...

    let mut buffer = BufReader::new(reader);
    let mut line = String::new();
    let mut cmd = Command::new();
    let mut mail = Mail::new();

    loop {
          ...

        match cmd.command {
            Some(SmtpCommand::Helo) | Some(SmtpCommand::Ehlo) => {
                ...
            }
            Some(SmtpCommand::Auth) => {}
            Some(SmtpCommand::Mail) => {
                if cmd.args.is_empty() {
                    let response = reply(
                        SMTP_STATUS_ERROR_SYNTAX,
                        "MAIL command requires an argument",
                    );
                    writer.write_all(response.as_bytes()).await?;
                } else {
                    let s = cmd.args[0].split(":").collect::<Vec<&str>>();
                    let r = s[1].replace("<", "").replace(">", "");

                    mail.from = r.replace(s[1], "");

                    let response = reply(SMTP_STATUS_OK, "OK");
                    writer.write_all(response.as_bytes()).await?;
                }
            }
            Some(SmtpCommand::Rcpt) => {}
            Some(SmtpCommand::Data) => {}
            Some(SmtpCommand::Rset) => {}
            Some(SmtpCommand::Noop) => {}
            Some(SmtpCommand::Quit) => {}
            None => {
               ...
            }
        }
    }

    Ok(())
}

Here is the output when you run the server and the client. You can see the RCPT command from the client. Next, we handle that command.

rust

Server is running...
New connection from 127.0.0.1:63732
Server: Service ready
Received: EHLO localhost
Server: HELO from server
Received: MAIL FROM:<sender@example.com>
Server: OK
Received: RCPT TO:<ujang@example.com>

Handle RCPT Command

Similar to the MAIL command, the client needs to send one argument containing the recipient email. The difference between the MAIL command and RCPT command is that the client can send more than 1 RCPT command for one SMTP session.

rust

async fn handle_connection(mut stream: TcpStream) -> Result<(), Box<dyn Error>> {
    ...

    let mut buffer = BufReader::new(reader);
    let mut line = String::new();
    let mut cmd = Command::new();
    let mut mail = Mail::new();

    loop {
          ...

        match cmd.command {
            Some(SmtpCommand::Helo) | Some(SmtpCommand::Ehlo) => {
                ...
            }
            Some(SmtpCommand::Auth) => {}
            Some(SmtpCommand::Mail) => {
                ...
            }
            Some(SmtpCommand::Rcpt) => {
                if cmd.args.is_empty() {
                    let response = reply(
                        SMTP_STATUS_ERROR_SYNTAX,
                        "RCPT command requires an argument",
                    );
                    writer.write_all(response.as_bytes()).await?;
                } else {
                    let s = cmd.args[0].split(":").collect::<Vec<&str>>();
                    let r = s[1].replace("<", "").replace(">", "");

                    mail.to.push(r.replace(s[1], ""));

                    let response = reply(SMTP_STATUS_OK, "OK");
                    writer.write_all(response.as_bytes()).await?;
                }
            }
            Some(SmtpCommand::Data) => {}
            Some(SmtpCommand::Rset) => {}
            Some(SmtpCommand::Noop) => {}
            Some(SmtpCommand::Quit) => {}
            None => {
               ...
            }
        }
    }

    Ok(())
}

And here is the output.

rust

Server is running...
New connection from 127.0.0.1:63985
Server: Service ready
Received: EHLO localhost
Server: HELO from server
Received: MAIL FROM:<sender@example.com>
Server: OK
Received: RCPT TO:<ujang@example.com>
Server: OK
Received: RCPT TO:<agus@example.com>
Server: OK
Received: DATA

Handle DATA Command

Data command contains the body and header part. Let’s take a look at the example:

C: DATA
S: 354 End data with <CR><LF>.<CR><LF>
C: From: "Bob Example" <[email protected]>
C: To: "Alice Example" <[email protected]>
C: Cc: [email protected]
C: Date: Tue, 15 Jan 2008 16:02:43 -0500
C: Subject: Test message
C:
C: Hello Alice.
C: This is a test message with 5 header fields and 4 lines in the message body.
C: Your friend,
C: Bob
C: .
S: 250 Ok: queued as 12345

The client sending DATA command to indicate the client start sending the mail data. The server needs to reply with 354, meaning the server is ready to receive the data. To indicate the header and body part, the client must separate the data with CRLF. And to indicate the end of the body, the client sends a single . on a line by itself.

First, we need to add a function to parsing the header and body on our Mail struct.

rust

#[derive(Debug)]
struct Mail {
    from: String,
    to: Vec<String>,
    header: HashMap<String, String>,
    body: String,
}

impl Mail {
    fn new() -> Self {
        ...
    }

    fn parse_data(&mut self, data: &str) {
        self.header.clear();
        self.body.clear();

        let lines = data.lines();
        let mut processing_headers = true;

        for line in lines {
            if processing_headers {
                if line.is_empty() {
                    processing_headers = false;
                } else {
                    if let Some((key, value)) = line.split_once(':') {
                        let key = key.trim().to_string();
                        let value = value.trim().to_string();
                        self.header.insert(key, value);
                    } else {
                        println!("Warning: Skipping malformed header line: {}", line);
                    }
                }
            } else {
                self.body.push_str(line);
                self.body.push_str("\r\n");
            }
        }

        self.body = self.body.trim_end_matches("\r\n").to_string();
    }
}

Then edit our handle_connection function.

rust

async fn handle_connection(mut stream: TcpStream) -> Result<(), Box<dyn Error>> {
    ...

    loop {
        ...

        match cmd.command {
            Some(SmtpCommand::Helo) | Some(SmtpCommand::Ehlo) => {
                ...
            }
            Some(SmtpCommand::Auth) => {}
            Some(SmtpCommand::Mail) => {
              ...
            }
            Some(SmtpCommand::Rcpt) => {
              ...
            }
            Some(SmtpCommand::Data) => {
                let response = reply(
                    SMTP_STATUS_SEND_DATA,
                    "Start mail input; end with <CRLF>.<CRLF>",
                );

                writer.write_all(response.as_bytes()).await?;

                let mut data: String = String::new();

                                // collect the data from client
                loop {
                    let mut data_line = String::new();
                    let bytes_read = buffer.read_line(&mut data_line).await?;

                    if bytes_read == 0 {
                        break;
                    }

                    if data_line == ".\r\n" {
                        break;
                    }

                    let line_to_append = if data_line.starts_with('.') {
                        &data_line[1..]
                    } else {
                        &data_line
                    };

                    data.push_str(line_to_append);
                }

                mail.parse_data(&data);

                let response = reply(SMTP_STATUS_OK, "Mail accepted");

                writer.write_all(response.as_bytes()).await?;
            }
            Some(SmtpCommand::Rset) => {}
            Some(SmtpCommand::Noop) => {}
            Some(SmtpCommand::Quit) => {}
            None => {
                let response = reply(
                    SMTP_STATUS_ERROR_COMMAND_UNRECOGNIZED,
                    "Unrecognized command",
                );

                writer.write_all(response.as_bytes()).await?;
            }
        }
    }

    Ok(())
}

Now you can run both the server and client. You can verify if our data parser is correct by printing the mail variable.

rust

Server is running...
New connection from 127.0.0.1:59925
Server: Service ready
Received: EHLO localhost
Server: HELO from server
Received: MAIL FROM:<sender@example.com>
Server: OK
Received: RCPT TO:<ujang@example.com>
Server: OK
Received: RCPT TO:<agus@example.com>
Server: OK
Received: DATA
Server: Start mail input; end with <CRLF>.<CRLF>
Server: Mail accepted
Received: QUIT

Handle RSET, NOOP, and QUIT Command

For the RSET, NOOP, QUIT is similar. we just reply to the client with different message. for the RSET command, we need to clear the mail.

rust

async fn handle_connection(mut stream: TcpStream) -> Result<(), Box<dyn Error>> {
    ...

    loop {
        line.clear(); // clear the line for each iteration

        // println!("Mail: {:?}", mail);

        let bytes_read = buffer.read_line(&mut line).await?;

        if bytes_read == 0 {
            println!("Connection closed by client");
            break;
        }

        println!("Received: {}", line.trim_end());

        cmd.parse(&line);

        match cmd.command {
            Some(SmtpCommand::Helo) | Some(SmtpCommand::Ehlo) => {
                  ...
            }
            Some(SmtpCommand::Auth) => {}
            Some(SmtpCommand::Mail) => {
              ...
            }
            Some(SmtpCommand::Rcpt) => {
              ...
            }
            Some(SmtpCommand::Data) => {
              ...
            }
            Some(SmtpCommand::Rset) => {
                let response = reply(SMTP_STATUS_OK, "Resseting the session state");

                writer.write_all(response.as_bytes()).await?;

                mail = Mail::new();
            }
            Some(SmtpCommand::Noop) => {
                let response = reply(SMTP_STATUS_OK, "I'm with you <3");

                writer.write_all(response.as_bytes()).await?;
            }
            Some(SmtpCommand::Quit) => {
                let response = reply(SMTP_STATUS_BYE, "Bye!");

                println!("mail: {:?}", mail);

                writer.write_all(response.as_bytes()).await?;

                break;
            }
            None => {
                ...
            }
        }
    }

    Ok(())
}

Now, you can running the application.

Server is running...
New connection from 127.0.0.1:59925
Server: Service ready
Received: EHLO localhost
Server: HELO from server
Received: MAIL FROM:<[email protected]>
Server: OK
Received: RCPT TO:<[email protected]>
Server: OK
Received: RCPT TO:<[email protected]>
Server: OK
Received: DATA
Server: Start mail input; end with <CRLF>.<CRLF>
Server: Mail accepted
Received: QUIT
Server: Bye!
mail: Mail { from: "[email protected]", to: ["[email protected]", "[email protected]"], header: {"To": "[email protected]", "From": "[email protected]", "Subject": "subject gonna be here"}, body: "\r\n\t<h1>Hello World</h1>\r\n\t<p>This is a paragraph.</p>\r\n\r\n\t<p>This is another paragraph.</p>\r\n\t<p>This is the last paragraph.</p>\r\n\r\n\t<p>And this is the last paragraph.</p>\r\n\t<p>And this is the last paragraph.</p>\r\n\t" }

Conclusion

Now, we have created our SMTP server without any external libraries. You may have noticed that we skipped the AUTH command. I’m going to explain it in the next articles.
